Product: Miniature circuit-breaker
Range : QO
Line Rated Current: 125 A
System Voltage:
120V AC
120/240 V AC
48V DC
Mounting Type: Bolt-on
Number of Poles: 2P
Circuit Breaker Type: Standard
Ratings: HACR rated
Electrical Connection: Box lugs
Interrupt Rating:
10 kA at: 120/240 V AC 50/60 Hz
10 kA at: 120 V AC 50/60 Hz
Number of Panel Spaces: 2
Wire Size: AWG 4...AWG 2/0 (copper or aluminium)
Height: 3.5 in
Depth: 2.91 in
Width: 1.5 in
Certifications:
CSA
UL listed
Ambient Rating: 104 °F (40 °C)
GTIN: 00785901031116
Package weight (Lbs): 0.739
Product environmental profile: Available
Warranty period: 18 months
