Square D Homeline™ 1-Pole Miniature circuit breaker features thermal magnetic molded case for extra protection. Circuit breaker has current rating of 15 Amps, voltage rating of 120/240 VAC and interrupt rating of 10 kilo-Amps. It accommodates copper/aluminum wire of range 14 - 8 AWG and copper wire range of 14 - 10 AWG.
The 1-Phase circuit breaker measures 1 Inch x 2.980 Inch x 3.130 Inch and provides long-time instantaneous trip functions to perform efficiently. It offers overload and short circuit protection for added safety. Circuit breaker features a common trip for easy indication and uses plug-on mounting to hold firmly. It is ideal for load center applications. Circuit breaker is UL listed/CSA certified and meets Fed. Specs W-C-375B/GEN standards.
SPECIFICATIONS :
Brand: Square D
Item: Miniature Circuit Breaker
Mounting: Plug-On
Number Of Poles: 1
Amperage: 20 A
Amperage Rating: 20 A
Voltage Rating: 120/240
Application: PROVIUPCDES OVERLOAD AND SHORT CIRCUIT PROTECTION
Connection: SCREW #12-6 AWG(AL/CU)
GTIN: 00785901065371
Interrupt Rating: 10KA
Dimensions: 1 Inch Width x 2.980 Inch Depth x 3.130 Inch Height
Length: 2.98 IN
Width: 3.8000
Special Features: STANDARD
Standard: UL LISTED - CSA CERTIFIED
Standards: UL Listed, CSA Certified, Fed. Specs W-C-375B/GEN
Sub Brand: HOMELINE
Trip Type: 6 Milliampere
Size: 1 in W x 2.98 in D x 3.13 in H
UPC: 785901065371
