Siemens P1E42MC250AT Type P1 Panelboard Interior, 480/277 VAC, 250 A

Siemens P1E42MC250AT

P1E42MC250AT Product Description

Siemens Low Voltage 3VA UL Molded Case Circuit Breaker With Thermal - Magnetic Trip Unit. 3VA41 Frame With High (Class H) Breaking Capacity. 20a 3-Pole (25kaic At 600y/347) (65kaic At 480v). Tm210 Trip Unit With Fixed IR Fixed II. Special Features: Lugs Installed In Load Side Only. Dimensions (W X H X D) In: 3 X 5.5 X 3.7.

SPECIFICATION:

Manufacturer:  Siemens
SKU: P1E42MC250AT
UPC: 887621663537
Amperage Rating : 250
Breaker Type :    BQD
Bus Material :    Aluminum
Dimensions : 44 in H x 20 in W x 5-3/4 in D
Enclosure Type : NEMA 1/3R/12
Housing Material : Steel
Product Type :    Simple
Type : Type P1
Unit Of Measure : EA
Voltage Rating : 277/480
Weight : 40.000 lb
Height : 7-1/2 Inch
Length : 39 Inch
Width : 16.000 in
Wiring Configuration :    4-Wire
