PLC Multipoint DD-P-120

DD-P-120 Product Description

PLC Multi Point DD-P-120 0-10V to Phase Dimming Converter, 600W, 120VAC Coil

Specifications:

Power Input Rating:100mA@120VAC, 60Hz
Operating Temperature: -30 degrees to 122 F
Humidity Range:5 to 95% (noncondensing)
Dimensions:4.00” x 4.00” x 1.80” with .50” NPT Nipple 16”
Wires:600V rated
Approvals:UL Listed, UL916, C-UL,
Housing Rating:RoHS UL Accepted, NEMA 1
Max Lighting Load:600W

Features:

0-10V Controlled Phase
Angle Dimmer
• 120VAC Input Power
• 600W max load
• Selectable Dimming
Mode
• Red LED for power
status

About PLC Multipoint:

For more than 30 years, PLC Multipoint has been making a name for itself as a creator and producer of the industry's finest lighting sensor controls and has earned a reputation as the go-to resource for solving the most complex lighting control challenges. PLC Multipoint’s product families include lighting control systems and daylighting sensors for a wide variety of applications.

Please email us with the products you need and the details of your job at buyriteelectric@gmail.com
