ELCO Lighting FV-0511VQ1

FV-0511VQ1 Product Description

WhisperCeiling® DC™ Precision Spot Ventilation Fan with built-in Pick-A-Flow™ speed selector switch allows you to select your required airflow (50-80-110 CFM). Features a ECM Motor with SmartFlow® technology and a Flex-Z Fast installation bracket. Can be used to comply with the latest codes and standards.

FEATURES :

Revolutionary ECM motor with SmartFlow™ technology for optimum CFM output
Pick-A-Flow™ Speed Selector – one fan, you choose the CFM (50, 80, 110 CFM models)
Flex-Z Fast bracket provides flexible, fast & trouble-free installation, even from below the ceiling
Lighted models incorporate one long-life, 10W dimmable LED chip panel with <1W LED night light for warm, energy efficient illumination
Elegant grille design compliments the aesthetics of any bathroom

SPECIFICATIONS :

Advanced Features : Single Speed
Air Volume (CFM) : 110, 111, 80, 83, 50, 53
Blower Wheel Type : Sirocco
California Title 24 Compliant : Yes
Current (Amps) : 0.18, 0.26, 0.11, 0.18, 0.07, 0.13
Duct Diameter : 4" or 6"
Energy Efficiency (CFM/Watt) : 10.6, 6.9, 13.6, 7.7, 12.5, 7.4
ENERGY STAR® Certified : Yes
Grille Size (in sq.) : 13"
Gross Weight (lbs) : 11.0
MAX. Current (Amps) : 0.27
Mfg in ISO 9001 Certified Facility : Yes
Motor Type (AC/DC) : DC
Mounting Opening (in sq.) : 10-1/2"
Noise (Sones) : <0.3, 0.9, <0.3, 0.6, <0.3, 0.4
Power Consumption (Watts) : 10.6, 16.4, 5.9, 10.8, 4.0, 7.2
Power Rating (V/Hz) : 120/60
Product Family Name : WhisperCeiling DC
Speed (RPM) 1342 1480 : 1016, 1268, 867, 1185, 768, 1097
Static Pressure in inches w.g. : 0.1, 0.25, 0.1, 0.25, 0.1, 0.25
Thermal Fuse Protection : Yes
Type of Motor Bearing : Ball
UL Listed for Tub/Shower Enclosure when GFCI Protected : Yes
UL tub/Shower Enclosure : Yes
Washington VIAQ Code : Yes

Labels and Listings :
Panasonic ventilation fans are ENERGY STAR certified, where guidelines exist. They've been engineered to comply with the ENERGY STAR® 4.0 requirement for increased efficiency (CFM/Watt), ensuring low cost, energy efficient operation. ENERGY STAR® vent fans meet strict parameters set by the US Environmental Protection Agency (EPA). They provide better efficiency and comfort with less noise, and feature high performance motors and improved blade design, providing better performance and longer life.

WhisperCeiling® DC™ was awarded 2018 Most Efficient. This mark recognizes WhisperCeiling® DC™ as delivering cutting edge energy efficiency along with the latest in technological innovation. It is an award that represents the best of those products that qualify for ENERGY STAR®.

Please email us with the products you need and the details of your job at buyriteelectric@gmail.com
