NORA Lighting NFLIN-8R-F

NFLIN-8R-F Product Description

Thin recessed LED designed for easy installation into new construction or remodel applications. Luminaire includes a quick connect that allows the junction box to easily disconnect and mounted in the ceiling. Junction box measures under 2" for shallow plenum ceilings where access above the ceiling is limited. High lumen output, the 4” unit produces the lumen output found in 6” units by others.

FEATURES :

Thin construction measures under 2" height
Special polymer lens
IC Air-Tight rated
Quick disconnect allows for easy installation
Up to 2350lm LED packages
2700K, 3000K, 3500K, 4000K or 5000K @ 90+ CRI
Driver is potted for quiet dimming and cooler operation
Triac or ELV dimming
cULus Listed for Wet Locations
5-year limited warranty

SPECIFICATIONS:

CONSTRUCTION
Construction: Thin construction measures 1.25" in height (8" LE4 measures 1.625" thick)

Lens: Regressed lens with sharp baffle cuts reduces aperture brightness. Special polymer lens produces more usable light and lumens per watt.

Driver: Electronic potted driver for quiet dimming and cool operation.

Junction Box: Pre Wired junction box includes quick connect to LED fixtures for ease of installation. Junction box includes four knockouts and snap on cover with 22” connector length. Through branch circuit wiring, (2-in, 2-out).

Mounting: No housing is required, two tensions steel spring clips secure luminaires to the ceiling. LE3 luminaires accept ceiling thicknesses from 3/8" to 15/16". LE4 luminaires accept ceiling thicknesses from 3/8" to 1-1/4". New construction frame-in kits are available, see accessories.

Minimum clearance: “IC” Insulated ceiling housings are direct contact rated; no minimum clearance is required. Airtight gasket provided.

ELECTRICAL
Voltage: 120VAC
Lumens / Wattage:
R407 = 800lm / 12W; S407 = 750lm / 12W;
R610 = 1450lm / 16W; S610 = 1150lm / 16W;
R815 = 1900lm / 20W; S815 = 1400lm / 20W;
R822 = 2350lm / 33W; S822 = 2350lm / 33W
Color Temperature: 2700K, 3000K, 3500K, 4000K, 5000K
CRI: 90+CRI
Operating Temp.:
407, 610, 815 = 0˚C to 40˚C ambient temperature 822 = 0˚C to 25˚C ambient temperature
Dimming: Dimmable down to 10% with Triac or ELV dimmer

LABELS AND LISTINGS
cULus Listed for Wet location
ENERGY STAR certified
Can be used to comply with 2016 Title 24 Part 6 high efficacy LED light source requirements
5-Year Limited Warranty
FCC Compliant
