Magnitude Lighting CVN96L36DC 36V Constant Voltage Non Dimmable LED Driver with Junction Box, Wattage 96W

2 sold in last 8 hours

CVN96L36DC

$121.00 $113.74
$113.74
customers are viewing this product

Magnitude Lighting CVN96L36DC

CVN96L36DC Product Description

This item is the Magnitude Lighting low voltage power supply part number CVN96L36DC. This driver has a universal input voltage of 120-277V and includes Auto Reset for over temperature, over load, and short circuit protection. As always, a 5 year warranty is standard on all of Magnitude's products. The output current 2700mA output with a max output power of 96 watts. This driver will operate any LED series of parallel string of LEDs designed for constant voltage input of 36V. It is IP66 rated and UL 8750 Approved, and Class 2, Class P rated.

Specifications:

Manufacturer: Magnitude Lighting
SKU:  CVN96L36DC
Family Constant Voltage LED Driver
Length (in) 11.4''
Width (in) 2.36''
Height (in) 1.4''
Voltage (V) 120-277VAC
Input Current 0.96A Max
Bulb Type LED
IP Rating IP65
Output Voltage 36V
Output Current 2700mA
Output Power 96W
Power Factor > 0.95
Type Constant Voltage
Start Temp. (Min) -25ºc
Start Temp. (Max) +40ºc
THD: < 20%
Mounting Length 12.1''
Weight (lb.) 1.934
UL Listed UL 8750, class 2, Class P
Warranty 5-year warranty

About Magnitude Lighting:

Magnitude Lighting’s advanced LED drivers and transformers bring innovation to commercial and residential lighting. Magnitude Lighting is an independent LED power company that focuses on LED drivers and transformers for Commercial, Industrial and Residential applications. With a remarkable longevity in LED Technology since 2008, Magnitude Lighting was one of the first companies in the industry to bring dimmable LED drivers into the lighting market.
