Lotus LED Lights L3G-RIT-BK-LB36-1895
L3G-RIT-BK-LB36-1895 Product Description
The L3G-RIT-BK-LB36-1895 is a versatile 3″ Tangra gimbal round downlight featuring an invisible trim design that delivers a clean, trimless ceiling appearance. Finished in black, it complements modern architectural interiors while the solid cast aluminum construction ensures durability and long-lasting performance.
This fixture is equipped with a lens beam (LB) optic and a 36° beam angle, providing balanced, controlled light distribution suitable for general illumination, accent lighting, and wall washing. The precision gimbal allows 45° tilt and 360° rotation, making it ideal for directional lighting and sloped ceiling installations.
Specifications:
SKU: L3G-RIT-BK-LB36-1895
Brand: Lotus LED Lights
Model: L3G-RIT
Series: Tangra 3" Gimbal Round Invisible Trim
Trim Color: Black (BK)
Trim Type: Invisible Trim
Construction: Solid cast aluminum body
Application: Task lighting, sloped ceiling up to 20°, wall washing, trimless
Power: 11W / 15W (user selectable with Lotus Tangra drivers)
Lumen Output: Up to 1600 lm at 3000K CRI95
Beam Angle: 36° (LB36)
Adjustability: 45° tilt and 360° rotation
Optics Type: LB – Lens Beam
Color Temperature: 1800K
CRI: 95
LED Type: COB LED
LED Options Category: 3000K–1800K CRI95 (2-step bin)
Dimming Range: Down to warm (1800K–3000K) / smooth dimming
Driver Type: 120V Triac dimmable (separate driver required)
Minimum Dimming: 3% reverse phase cut / 4% forward phase cut
Fixture Input: 120V AC / 50–60Hz (via driver)
Cutout Size: 3 1/4"
Ceiling Type: Requires space above ceiling for driver (4")
J-Box Wire Volume: Max 5 No 12 AWG or 8 No 14 AWG with FF/MC cable
Operating Temperature: -40°F to 113°F (-40°C to 45°C)
Projected LED Life: 70% light output at 50,000 hours
Certifications: cETLus, FCC Type IC, Air Tight, Open Plenum, Wet Location IP54
Warranty: 5 years (fixture)
