Leviton 8280 Decora Plus Surge Protective Isolated Ground Duplex Receptacle Outlet 125V AC

2 sold in last 8 hours
LEVITON
8280-IGW
$48.00
$48.00
customers are viewing this product
Leviton Decora Plus® 2-Pole 3-Wire Type 3 Straight blade surge protective receptacle in white color has nylon face and body construction for long lasting durability. It comes with surge indicator light. It has a voltage rating of 125 Volts and current rating of 15 Amps. Receptacle can withstand a maximum temperature rise of 30 deg C after 250 cycles OL at 200% rated current. It withstands up to 2000 Volts dielectric voltage rated under UL 498 standards. Receptacle has a flammability rated at V-2 per UL94. It has an operating temperature range of -40 to 60 deg C.

Receptacle has NEMA 5-15R configuration. Grounding and terminal screws are made of 8 - 32 and 10 - 32 brass. Yoke and clamp nuts are made of corrosion resistant zinc-plated steel. Ground clips are made of corrosion resistant brass plated steel. It has triple-wipe line contacts made of brass. Hot, ground and neutral terminals have brass, green and white color respectively. It has 14 - 10 AWG terminal accommodation.

Receptacle has a maximum continuous operating voltage of 150 Volts RMS and an energy rating of 720 J. It has a short circuit current rating of 5 kilo-Amps. Hospital grade receptacle has maximum surge current of 24 kilo-Amps per mode and a noise rejection ratio of -30 dB at 500 kilo-Hz - 30 mega-Hz. It has voltage protection rating of L-N: 600 Volts, L-G: 700 Volts, N-G: 600 Volts. Receptacle is UL listed/CSA certified and meets NEMA/ANSI/NOM standards.

FEATURES:

Amperage: 15 A
Body Material: Nylon
Brand: Decora Plus
Color: White
Device Type: Duplex Receptacle Outlet
Diagnostics: Indicator Light & Audible Alarm
Face Material: Nylon
Feature: Surge
Function: Surge Protective Isolated Ground
Grade: Heavy-Duty Hospital Grade
Grounding: Self-Grounding
Joules Rating: 720
Max Surge Current L-N: 24kA
NEMA: 5-15R
Noise Rejection: -30dB at 500kHz-30MHz
Pole: 2
Standards and Certifications: UL/CSA
Strap Material: Steel
Termination: Back or Side Wire
UL1449 Impulse 6kV/500A L-N: 400V
Voltage: 125 VAC
Warranty: 10 Year Limited
Wire: 3

SPECIFICATIONS:

AC Horsepower Ratings
At Rated Voltage: 1/2 HP

Electrical
Amperage: 15 A
Current Limiting: Full Rated Current
Dielectric Voltage: Withstands 2000V per UL498
Grounding: Self-Grounding
Pole: 2
Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
Voltage: 125 VAC
Wire: 3

Environmental
Flammability: Rated V-2 per UL 94
Operating Temperature: -40°C to 60°C

Material
Body Material: Nylon
Clamp Nuts: Zinc-Plated Steel
Face Material: Nylon
Grounding Screw: Brass 8-32
Line Contacts: Brass Triple-Wipe
Terminal Screws: Brass 10-32
Yoke: Zinc-Plated Steel

Mechanical
Product ID: Ratings are permanently marked on device
Terminal Accom.: 14-10 AWG
Terminal ID: Brass-Hot, Green-Ground, White-Neutral
Termination: Back or Side Wire

Performance Data
Diagnostics: Indicator Light & Audible Alarm
Joules Rating: 720
MCOV: 150V rms
Max Surge Current L-N: 24kA
Noise Rejection: -30dB at 500kHz-30MHz
Short Circuit Current Rating: 5kA
UL1449 Impulse 6kV/500A L-N: 400V
VPR: L-N:600V, L-G:700V, N-G:600V

Standards and Certifications
ANSI: C-73
CSA C22.2 No. 42: File 152105
NEMA: WD-6
NOM: 057
UL498HG: File E13399
