Leviton 25249-SBA Nickel Duplex Floor Box 15A / 125 V

2 sold in last 8 hours
LEVITON

25249-SBA

$60.00
$60.00
customers are viewing this product
Gang Floor Box Receptacle Assembly, Includes Brass with Brushed Nickel Finish Floor Plate, Gasket, Screw Cap, O-ring, and Switch Box. NOTE: O-Ring Should be Assembled On Cap. Receptacle 15A-125V, 2-Pole, 3-Wire, Grounding, NEMA 5-15R. NICKEL

For low profile, in-floor receptacle installations, our Floor Box Receptacle Assemblies are the perfect fit. Available in both 15 & 20 Amp 1- and 2-gang configurations, these devices are suitable for wood frame construction with carpet, wood, tile, and vinyl finished flooring. Common applications include a variety of uses from home office workstations to high-end stages and entertainment venues.

FEATURES:

Amperage: 15 A
Color: Ivory/Brushed Nickel Finish
Grounding: Self Grounding
NEMA: 5-15R
Voltage: 125 VAC

SPECIFICATIONS:

Electrical
Amperage: 15 A
Current Limiting: Full Rated Current
Dielectric Voltage: Withstands 2000V per UL498
Grounding: Self Grounding
Pole: 2
Temperature Rise: Max 30C after 50 cycles OL at 150 percent rated current
Voltage: 125 VAC
Wire: 3

Environmental
Flammability: Rated V-2 per UL 94
Operating Temperature: -40°C to 60°C

Material
Body Material: Nylon
Clamp Nuts: Zinc-Plated Steel
Color: Ivory/Brushed Nickel Finish
Face Material: Nylon
Floorplate Material: Solid Brass 0.060 In Thick
Ground Clips: Brass-Plated
Grounding Screw: Brass 8-32
Line Contacts: Brass Triple-Wipe .031 Thick
Strap Material: Zinc-Plated Steel
Terminal Screws: Brass 10-32

Mechanical
Product ID: Ratings are permanently marked on device
Terminal Accom.: 14-10 AWG
Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
Termination: Back & Side

Standards and Certifications
ANSI: C-73
CSA C22.2 No. 42: File E152105
NEMA: WD-6
NOM: 057
UL498: File E13399
Warranty: 10 Year Limited
