Intermatic PX300

PX300 Product Description

These safety transformers are specifically designed to supply 12-13 VAC and are suitable for direct connection to underwater pool/spa lights. A grounded shield between the primary and secondary winding assures safe operation.

Features:

Mounting brackets on the top and bottom
Built-in circuit protection disconnects power temporarily in case of overload
Complies with NEC Code 680.23 requirements for underwater luminaries

Specifications:

Brand: Intermatic
Part Number: PX300
Enclosure Type: 3R Beige metal
Input Voltages: 3 A, 120 VAC, 60 Hz
Knockout Dimensions Back/Side: (2) combination 1/2" - 3/4"
Knockout Dimensions Bottom: (4) combination 1/2" - 3/4"
Knockout Dimensions Left: (2) combination 1/2" - 3/4"
Knockout Dimensions Right: (2) combination 1/2" - 3/4"
Maximum Power Consumption (W): 300 W
Other Certifications and Compatibilities: NEC Code 680.23
Output Voltages: 12 VAC, 13 VAC, 14 VAC
Product Depth (in): 4.5
Product Depth (mm): 114.3
Product Height (in): 7.25
Product Height (mm): 184.2
Product Width (in): 5.25
Product Width (mm): 133
Transformer Input Voltage: 3 A, 120 VAC, 60 Hz
Transformer Output Voltage: 12, 13, 14 VAC
Transformer (W): 300
Warranty: 1-Year limited

About Intermatic:

Our product portfolio broadened to include industrial- and commercial-grade controls starting in 1990 and would soon expand with a variety of progressive, energy-saving solutions. Today, Intermatic offers an extensive catalog of lighting and energy controls, surge protection devices, weatherproof covers, and Wi-Fi-enabled solutions as we continue to evolve and push the industry forward.
