EnvisionLED LED-EMB-32W-HV-0/10V

LED-EMB-32W-HV-0/10V Product Description

This High Voltage Emergency Backup features a 170VDC output with a universal input voltage range of 100-347VAC and a 15W AC input power rating. Equipped with a Li-Ion battery, it provides 90 minutes of emergency backup and supports a 32W output power. It includes a low-voltage illuminated test switch and a 500mA battery charging current with a 24-hour recharge time. With a 5-year warranty and an operating temperature range of 0˚F to 122˚F, it ensures reliable performance for emergency lighting applications.

Specifications:

Brand: EnvisionLED
SKU: LED-EMB-32W-HV-0/10V
UPC: 810143715613
Output Voltage: 170VDC
Universal Input Voltage: 100-347VAC, 50/60Hz
AC Input Current: 200mA Max.
AC Input Power Rating: 15W
Emergency Time: 90 Minutes
Full Warranty: 5 Years
Output Power: 32W
Test Switch/Charge Light: Low Voltage, Illum. Test Switch
Battery Charging Current: 500mA
Recharge Time: 24 Hours
Temperature Rating (Ambient): Li-Ion 0˚F to 122˚F
Output Current: 460mA
