EMCOD MLE192C2-24UD

MLE192C2-24UD Product Description

EMCOD 192W Electronic Universal 5 in 1 Dimming LED Driver, 100-277V 50/60Hz, Black Powder Coated Steel Enclosure

Specifications:

Transformer
Dimmable with triac forward and reverse phase, 0/1-10V , resistor, PWM
Temperature class B(130°C)
Input leads are 18AWG 600V
Output leads are 16AWG 300V
Leads max. operational temperature is 105°C
per circuit

Housing
The actual transformer 192W is encapsulated in the enclosure
The enclosure is Black Powder Coated Steel, NEMA 3R rated
Wiring compartment has 10 knockouts sizes for 3/8 inch screw cable
connectors
Enclosure Temperature does not exceed 70°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 6.83, W = 11, D = 1.85
Weight (LBs): 4.4
