EMCOD ML100S12AC Class 2 Magnetic LED AC Driver Outdoor Phase cut Dimmable Black Powder Coated Steel Enclosure
ML100S12AC
EMCOD ML100S12AC
ML100S12AC Product Description
EMCOD Class 2 Magnetic LED AC Driver Outdoor Phase cut Dimmable Black Powder Coated Steel Enclosure
Specifications:
Transformer:
Dimmable with compatible MLV, ELV, CL dimmers, please refer to list on
emcod.com
Temperature class B(130°C)
Input leads are 18AWG 600V
Output leads are 18AWG 300V
Leads max. operational temperature is 105°C
Thermal self reset primary breaker 2A
Thermal self reset secondary breaker 13A
Housing:
The actual transformer 100W is encapsulated in the enclosure
The enclosure is Black Powder Coated Steel, NEMA 3R rated
Wiring compartment has 5 knockouts sizes for 3/8 inch screw cable
connectors
Enclosure Temperature does not exceed 75°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 8.13, W = 3.93, D = 1.59
Weight (LBs): 4.35
About EMCOD:
EMCOD is a world-class developer and manufacturer of LED drivers, Lighting and custom made general-purpose transformers for electronic and electrical equipment. Emcod Lighting group’s advanced LED drivers and transformers bring innovation to commercial and residential lighting.
