ELCO Lighting EL88140W

EL88140W Product Description

ELCO Lighting 8" Square insert is engineered with energy-efficient LED technology that produces even illumination with an incredible 93+ CRI. Designed to be used for retrofitting 8" Square Housings with medium base socket like EL8SQ and EL8SQICA these inserts are rated for a life of 50,000 hours, and meet the Title 24 and Energy Star requirements. Suitable for IC and Non-IC housings manufactured by ELCO or others.


Dimmable Square LED Retrofit.
Includes Medium Base Adapter for retrofitting existing E26 Base housings.
High efficacy LED arrays mounted directly to cast aluminum housing providing superior thermal management to ensure LED longevity.
Soft white lens provides smooth lumen distribution and eliminates LED pixelation.
Die-Cast construction provides lasting durability.
CA Title 24, ENERGY STAR, JA8-2016.
Lifespan of 50,000 hours L70.


Wattage : 19W
Lumens : 1460 lm - 1520 lm
Voltage : 120/277V
Color Temp. : 3000K - 4000K
Dimmable : Triac/ELV
Lamp Type : LED
Wet Location : Listed

Optics: Frosted polycarbonate lens diffuses light evenly throughout while reducing glare with LED Array technology.

Construction: For use in IC and non-IC housings. Diecast construction for lasting quality and greater heat dissipation. High quality powder coat finish preventing rust and paint cracking.

Installation: Includes PSA30 medium base adapter for retrofitting existing housings. Quick connect for use with ELCO housings EL8SQICA, EL8SQ.

Electrical: Driver connects to 120/277V power supply. High Efficient driver with a power factor > 0.9. Start time of less than .75 seconds.

LED Technology:
Extremely accurate color rendering with 93+ CRI.
Lumen Maintaince of 50,000 hours L70 Life based on LM80 standardized test results.
Superior Thermal Management by utilizing integral heat sink.
Instant On to Full Brightness.
No LED pixelation.

Dimmability: Works with 120V Triac and ELV type dimmers. Dims down to 10%. For full list of dimmers refer to the Dimmer Compatibility List.

Warranty: ELCO Products are built to last. 5-year Limited Warranty.

Labels and Listings:

UL Listed for Wet Location
RoHS Compliant
ENERGY STAR® Certified
California Title 24 JA8-2016
