ELCO Lighting EL511CT5W LED 15W 5 Inch Sloped Ceiling Baffle Inserts 1050 lm White Finish
EL511CT5W
ELCO Lighting EL511CT5W
EL511CT5W Product Description
Sloped Ceiling LED inserts feature an integral gimbal for ±25° adjustability. Compatible with most incandescent and electronic low voltage dimmers.FEATURES :
5" Sloped Ceiling LED Inserts feature an integral gimbal for ±25° tilt adjustability.Compatible with most incandescent and electronic low voltage dimmers.
ENERGY STAR® Certified. California Title 24 (JA8-2016-E).
Life Span: 50,000 hours L70.
SPECIFICATIONS :
Wattage : 15W
Lumens : 1050 lm
Voltage : 120V
Color Temp. : 2700K - 5000K
Dimmable : Triac/ELV
Lamp Type : LED
CRI : 90+
Damp Location : Listed
Optics: LED light engine has frosted polycarbonate lens with reflector to diffuse light evenly while reducing glare.
Construction: Deep baffle trim with torsion springs to be held into the housing. High quality powder coat finish preventing rust and paint cracking on metal parts. Integral gimbal allows for 25° adjustability to match slope.
Installation: Designed to install into ELCO 5” Sloped ceiling housing with torsion springs brackets. For retrofitting other manufacturers sloped ceiling cans always test the product to ensure proper fit and function.
Electrical:
Driver connects to 120VAC power supply.
High efficiency, high power factor > 0.9 driver.
LED Technology:
Accurate color rendering with 90+ CRI.
Lumen Maintenance of 50,000 hours L70 Life based on LM80 standardized test results.
Superior Thermal Management by utilizing aluminum die cast heat sink.
Dimmability:
Dimmable with most standard TRIAC and ELV type dimmers.
Dimming range of 100% down to 10%. Dimming range may vary depending on dimmer model. For full list of dimmers refer to the Dimmer Compatibility List.
Warranty: ELCO Products are built to last. 5-year Limited warranty
Labels and Listings:
UL Listed for Damp Location.
ENERGY STAR® Certified.
California Title 24 (JA8-2016-E).
