Elco Lighting EL49FICA-GU10

EL49FICA-GU10 Product Description

Introducing FireProof™ Lighting Our new fire-rated housings are built with non-combustible materials that guarantee safe lighting for both commercial and residential ceilings. In the event of a fire the recessed fixture can withstand flames, heat, and gasses for a minimum of two hours, thus eliminating leakage into duct work. Easy to install. Maintenance free. This self-contained housing is not only available in several sizes and trims to complement any design, it also provides excellent sound reduction between floors.

FEATURES :

For use in insulated ceilings.
Integrated non-combustible insulation enhances acoustical protection, dampening sound transfer between floors.
GU10 socket for LED and traditional GU10 lamps.

SPECIFICATIONS :

Construction:
Double wall IC rated for direct contact with insulation. For use in IC and non-IC conditions.
Housing adjusts in frame to accommodate up to 1 1/2" ceiling thickness.
Airtight housing with gasket to restrict airflow in accordance with ASTM E-283 air- tight requirements.

Installation:
Designed for ceiling plenums where 2x8 joists or taller are used.
High strength hanger bars can easily be nailed to joists.
Suitable for T-grid and drop ceiling applications.
See installation sheet for detailed information.

Junction Box: Positioned to accommodate straight conduit runs. Two 3/4” knockouts, Seven 1/2” trade size
conduit knockouts, One 3/8" knockout. Four Pry-out knockout slots for easy romex installation.

Hanger Bars: Pre Installed hanger bars with True Nail easy installation in regular lumber, engineered lumber, and Laminated Beams. Integral T-bar slots for easy installation in T-Bars. Spans up 24" and can be repositioned 90°. Score lines allow for tool-free hanger bar size reduction. Integral leveling flange allows for single-person installation while easily aligning the housings with the joists.

Trims: Compatible with ELCO 4" GU10 trims.

Labels and Listings:
UL Listed for Damp Location
Wet Location with select trims
UL Listed for Direct Contact with Insulation
Combustible Material
UL Listed for Feed Through
UL Classified 2-hour fire rating

About Elco Lighting

Founded in 1991 by its president, Steve Cohen, ELCO Lighting develops and markets lighting products for commercial and residential applications. Founded on the philosophy that high-quality commercial and residential lighting should be sold at a fair market price, Elco Lighting has designed and engineered lighting for residential and commercial spaces for almost two decades. Their product line includes track and recessed lighting fixtures, exit and emergency lights, under cabinet lighting, wall packs, step lights and more.

Please email us with the products you need and the details of your job at buyriteelectric@gmail.com
