ELCO Lighting E2LCU86ICA 11W 2" IC Airtight HIGHTECH Housings 120/277V

2 sold in last 8 hours

E2LCU86ICA

$69.23
$69.23
customers are viewing this product

Elco Lighting E2LCU86ICA

E2LCU86ICA Product Description

Single Wall IC listed for direct contact with insulation.
Triac/ELV/0-10V (120-277V), Triac/ELV (120V only).
Height allows for use in 2x4 construction.
Driver included on housing.
CA Title 24 compliant (JA8-2016-E).
LED Light Engine sold separately.
U.S. Patent 10,281,131.

SPECIFICATIONS :

Wattage 11W
Voltage 120/277V or 120V
Dimmable Triac/ELV/0-10V,
Triac/ELV
Wet Location Listed

Construction:
IC Rated for Direct Contact with Insulation, for use in IC and Non-IC conditions.
Housing adjusts in frame to accommodate up to 1 1/4" ceiling thickness.
Aluminum housing for greater heat dissipation. Stamped galvanized steel frame.
Driver mounted on junction box for cooler LED operation.

Installation: Designed for shallow ceiling plenums where 2x4 joists or taller are used. High strength hanger bars can easily be nailed to joists. Maximum hole cutout is 2 5/8”. Suitable for T-grid and drop ceiling applications. See installation sheet for detailed information.

Junction Box: Positioned to accommodate straight conduit runs. Two 1/4” trade size pry-out knockouts with conduit fitting. Strain clamps to install or remove covers for easy access and grounding.

Hanger Bars: Pre-installed hanger bars with True Nail easy installation in regular lumber, engineered lumber, and Laminated Beams. Integral T-bar slots for easy installation in T-Bars. Spans up 24" and can be repositioned 90°. Score lines allow for tool-free hanger bar size reduction. Integral leveling flange allows for single-person installation while aligning the housings with the joists.

Electrical: Driver connects to 120V only or 120/277V power supply. High Efficiency driver with a power factor > 0.9.

Dimmability: Works with 120V Triac and ELV type dimmers, and 120-277V 0-10V dimming. Dims down to 10%. For full list of dimmers refer to the Dimmer Compatibility List.

Warranty: ELCO Products are built to last with a 5-year Limited warranty.

Labels and Listings:
UL Listed for Wet Location.
UL Listed for Feed Through.
Meets restricted airflow requirements (per ASTM E-283).
ENERGY STAR® Certified.
California Title 24 (JA8-2016-E).

About Elco Lighting

Founded in 1991 by its president, Steve Cohen, ELCO Lighting develops and markets lighting products for commercial and residential applications. Founded on the philosophy that high-quality commercial and residential lighting should be sold at a fair market price, Elco Lighting has designed and engineered lighting for residential and commercial spaces for almost two decades. Their product line includes track and recessed lighting fixtures, exit and emergency lights, under cabinet lighting, wall packs, step lights and more.
