Cutler Hammer Br215 15 Amp 2-Pole BR Plug-On Circuit Breaker 120 / 240VAC

A Branch Feeder Type Arc Fault Circuit Interrupter is a device intended to mitigate parallel arcing faults in the complete circuit, including connected cords. Parallel arcing faults can occur from line to neutral or line to ground. These arcing faults are in parallel with the load and produce the most energy of all arcing faults.Moreover It's a type BR 10,000 Amperes Interrupting Capacity 120 VAC and 120/240 Vac

FEATURE :

Product Name : Type BR 1-inch Plug-on Circuit Breaker
Catalog Number : BR215
Compliances : Federal Specifications Classification W-C375
Certifications : Ul 489

SPECIFICATIONS :

Mounting : Plug-on
Special Features : used With Type Br Load Centers
Interrupt Rating : 10 Kaic
Type : Type Br 1-inch Plug-on Circuit Breaker
Wire Size : #14-4 AWG CU/Al
Used With : Type Br Load Centers
Main Circuit Breaker : BR
Voltage Rating : 120/240v
Amperage Rating : 50A
Number of Poles : Two-pole
Quantity : Q28
Voltage Rating : 120/240v
Amperage Rating : 15A
Trip Type : Common
Number of Poles : Two-pole

Please email us with the products you need and the details of your job at buyriteelectric@gmail.com
