Westgate T8-4FT-18W-50K-D-F

T8-4FT-18W-50K-D-F Product Description

18W 4Ft Frosted Led Plastic Tube Lamps 90~140V

SPECIFICATIONS:

Voltage: 90~140V (Dimmable)
Chip: 132 SMD2835
Beam spread: 120°
Base: fits standard T8 or T12 sockets (G-13)
Ambient operating temperature: -10°C to 30°C
Requires no ballast. Existing ballast must be bypassed and one socket wired directly to line voltage
Dimmable: Yes
Special Order: Available in 3”6” and 8” lengths, frosted lens, or with a dimmable driver.
Use part number PXTEU-16-specified color.
T-8 LED lamp operates on line voltage. Ballast must be disconnected and bypassed. One socket wired to line voltage
Heat sink: 6063 extruded aluminum with heat dissipation ribs for superior thermal management
4ft LED tube available in 16-watt in a red, blue, green and yellow color in stock.
Rated life: 50,000 hours

Warranty: 5 years

APPLICATIONS:
Ideal for offices, retail stores, showrooms and residential applications. Especially suited for areas where accessing the fixture is challenging. Rated for use in open fixtures only. Not for use in enclosed.

About Westgate:

Westgate's full line of LED Outdoor lighting products is designed using high performance 5th generation COB technology and carries an industry first. Shop for Westgate Lighting LED products, we offer a wide range of indoor, outdoor light bulbs and fixtures.
