Perimeter lighting for safety, security and identity. Applications include office buildings, shopping centers, restaurants, schools, warehouses, parking garages and other commercial areas.Typical mounting is 12-15ft with typical spacing of 60-75ft.
SPECIFICATIONS :
Available in energy saving LED, replacing up to 250w HID systems
One-piece poly carbonate lens, internally painted for lasting appearance. 6 to 1 spacing to mounting height ratio. Two HubbellGard fastners provide weathertight seal to housing. Door hinges and is removable.
Housing is die cast aluminum for rugged mounting and heat dissipation. 1/2" feed-thru side hubs provided and top photo control hub for easy field installation. Standard mount is over recessed wiring boxes.
Specular reflector, vertical lamp and refractor combine for efficient and uniform perimeter lighting. Max wattage is 150PS or 150HPS. 50HZ ballastry available.
Socket is porcelain medium base with spring-loaded center contact.
Certifications
CSA
Wet listed
