Extra large LED flood with a variety of NEMA distribution for lighting applications such as safety/ security, accent, flag pole, columns, area or signs
SPECIFICATIONS :
Corrosion resistant, rugged die-cast aluminum housing with powder coat paint finish
Tempered glass lens protects LEDs and allows for easy cleaning/debris removal
Vented housing isolates LED module from driver, maximizing product life and performance
Visor, louver and vandal accessories available
LED:
56 high powered LED’s deliver up to 21,000 lumens
5000K CCT 70 CRI or 4000K 70 CRI
84 high powered LED’s deliver up to 21,000 lumens
5000K CCT 70 CRI, 4000K 70 CRI, 3000K 80 CRI
Optical/Electrical:
Variety of NEMA distributions - N (3x3), M (4x4),RM (5x4) and W (6x6) - for wide range of lighting applications
120-277V operation, 50/60Hz, 187W, 1050mA, up to 112 LPW (56LED)
120-277V, 347V and 480V operation, 50/60Hz, 193W, 700mA, up to 111 LPW (MTO – 84LED)
10KA surge protector comes standard
0-10V dimming driver standard, continuous dimming option to have leads pulled out for easy connection
Installation:
Knuckle mount 15˚ aiming angle increments for precise aiming and control, fits 2-3/8" tenons or pipes
Heavy duty steel yoke with adjustable stainless steel hardware, mounting holes for one center - 3/4" bolt or two side - 3/8" bolts
3' SEOOW cord with voke mount
Listings:
IP65, Listed to UL1598 for use in wet locations
Select Models DLC Standard and DLC Premium Qualified.
EPA = 1.85ft2
