Elco Lighting ELB50R40 Birch™ High Lumen LED Module, Color Temperature 4000K, Lumens 3200, 4000, 5000 lm, Beam Angle 22° to 50°

ELCO Lighting ELB50R40

ELB50R40 Product Description

The beautifully designed die-cast module houses powerful and advanced LED technology to provide increased durability and outstanding illumination. Works with 4", 6" & 8" Birch Commercial Frames, Remodel, Retrofits and Twist-On Trims.

FEATURES :

Non-IC for use in Non-IC applications
Select Lumen Output (1250 lm to 5000 lm) by using manual switch on module
Adjustable Focus Beam Angle allows for manual beam angle adjustment from 22˚ to 50˚ range with the ease of a twist
Featured Twist-On mechanism to easily lock module to any size trim
Encased Quick Connector for easy module installation
ELB30R works in 4", 6", and 8" Commercial Frames, Remodel and Retrofit applications
ELB50R works with 6" & 8" Commercial Frames, Remodel and Retrofit applications Only. Only for use with ELB610 and ELB810 trims
120/277V input with 0-10V dimming
Excellent color rendering 93+ CRI
Meets Energy Star Requirements
ETL listed for damp location
Life span of 50,000 hours L70

SPECIFICATIONS :

Wattage 32W / 40W / 55W
Lumens 3200 lm / 4000 lm / 5000 lm
Voltage 120/277V
Color Temp. 4000K
Dimmable 0-10V
Lamp Type LED
Beam Angle 22° to 50°
CRI 93+
Damp Location Listed

Technical Details

Optics: Frosted polycarbonate module lens diffuses light evenly throughout while reducing glare with LED technology.

Construction: Integrated driver and light engine with Encased Quick Connect. Diecast aluminum body with heat fins allows for efficient cooling.

Installation: Twist-On design for tool-less trim installation, for use with Birch™ Trims. ELB30R can be used in 4", 6", and 8" Commercial Frames and Remodel/Retrofit applications with Encase Quick Connect base. ELB50R can be used in 6", and 8" Commercial Frames and Remodel/Retrofit applications with Encase Quick Connect base and only for use with ELB610 and ELB810 trims. For use in non-IC applications.

Electrical: Module connects to 120/277V power supply. High-efficiency driver with a power factor >0.9. Start time of less than 0.75 seconds.

LED Technology: Extremely accurate Color Rendering Index of 93+. Lumen Maintenance of 50,000 hours L70 Life span. Superior Thermal Management by utilizing integrated heat sink. Instant On to Full Brightness technology. No LED pixelation.

Dimmability: 0-10V dimmable. Dims down to 5%. For a full list of dimmers, refer to the Dimmer Compatibility List. Industry-leading dimming that dims smoothly with no hot spots or flickering.

Listings: ETL Listed for Damp Location.
