ESL Vision ESL-CP-R-2555W-13050-WH LED Round Canopy Light, Selectable Wattage 25W–40W–55W, MCTP 3000K–4000K–5000K, White Finish

ESL Vision ESL-CP-R-2555W-13050-WH

ESL-CP-R-2555W-13050-WH Product Description

The ESL Vision ESL-CP-R-2555W-13050-WH is a high-performance rectangular LED canopy light engineered for commercial and industrial applications. Featuring selectable wattage (25W–40W–55W) and tunable CCT ranging from 3000K to 5000K, this versatile fixture is ideal for gas station canopies, parking garages, building soffits, and architectural lighting. With a durable white finish, IP65 rating, and robust thermal design, it ensures reliable operation in demanding environments while delivering energy-efficient, high-quality illumination with minimal maintenance.

Specifications:

Model: ESL-CP-R-2555W-13050-WH
Series: Rectangular LED Canopy Light
Selectable Wattage: 25W / 40W / 55W
Selectable CCT: 3000K, 3500K, 4000K, 5000K (Tunable)
Lumen Output: Up to 7,920 lm (estimated based on 144 lm/W efficacy)
Efficacy: Up to 144 lm/W
CRI: >80
Input Voltage: 120–277V AC
Power Factor: >0.9
THD: <10%
Rated Life (L70): 100,000 hours
Beam Angle: 120°
IP Rating: IP65 (Dust-tight, protected against water jets)
Operating Temperature: -40°F to 122°F (-40°C to 50°C)
Dimensions (L × W × D): Estimated 16–18" L × 9.45" W × 3.94" D (confirm with spec sheet)
Weight: Approx. 7–9 lbs
Finish: White (WH)
Mounting: Surface mount for flat canopies & ceilings
Warranty: 5-year limited warranty
Certifications: UL / cUL / DLC / RoHS / IP65
Applications: Gas stations, parking garages, loading docks, building canopies, industrial soffits
