Westgate XT-C-ADJ-3GBBEM

XT-C-ADJ-3GBBEM Product Description

LED Red Single/Double Faceplate Combination LED Exit Sign and Emergency 120/277V

SPECIFICATIONS:

ELECTRICAL SPECIFICATIONS:
• Voltage: Dual 120-277V
• Wattage: 6W
• Lamp head wattage: 3W pre head

TECHNICAL SPECIFICATIONS:
• Solid state electronics and charger board
• Push-to-test switch
• Specification grade exit with Premium high-output ultra
bright LEDs
• 8.4V, Rechargeable Ni-Cad battery
• 90-minute EM-rated with push style test switch and red
indicator light
• Optional Remote capacity available

HOUSING SPECIFICATIONS:
• Universal canopy for side or top mounting on wall or
ceiling
• Two fully adjustable LED heads
• Single or double faceplates
• Left and right arrow (Chevron)
• Low profile compact design,
• Mounting accessories included
• Suitable for damp location (32°F to 122°F )

WARRANTY: 3 years
• Meets UL924, NFPA life safety code, Local and State codes,
NEC,OSHA
