Siemens LGB3B035B

LGB3B035B Product Description

Siemens low voltage panelboard mount g frame circuit breaker with thermal - magnetic trip. UL listed LGB frame with very high breaking capacity. 35A 3-pole (14KAIC at 600Y/347V) (65KAIC at 480Y/277V). Special features mounts on panelboard , load side lugs only (TC1GG20) wire range 8 - 1/0 AWS (cu/al). Dimensions (w x h x d) in 3 x 5.4 x 2.8.

SPECIFICATION:

Manufacturer:  Siemens
SKU: LGB3B035B
UPC: 887621220259
Amperage : 35 Amp
Applications : INDUSTRIAL
Connection Type : Low Tab Panelboard Mount
Frame : 125A
Frequency : 50/60 Hz
Interrupt Rating : 65 kAIC
Material : MOLDED CASE CIRCUIT BREAKER
Number of Poles : 3 Pole
Operating Temperature : 40DEGC
Standard : UL 489,CSA-C22.2
Tc Connection : LOW TAB PANELBOARD MOUNT
Trip Type : THERMAL MAGNETIC TRIP UNIT
Type : LGB
Voltage : 480 Volt
Weight : 2.7500 lb
Height : 4.99 Inch
Length : 2.87 Inch
Width : 2.960
