Siemens LGB3B030B

LGB3B030B Product Description

Siemens low voltage panelboard mount g frame circuit breaker with thermal - magnetic trip. UL listed LGB frame with very high breaking capacity. 30A 3-pole (14KAIC at 600Y/347V) (65KAIC at 480Y/277V). Special features: mounts on panelboard, load side lugs only (TC1Q1) wire range: 14 - 10 AWS (CU/AL). Dimensions (w x h x d) in: 3 x 5.4 x 2.8.

SPECIFICATION:

Manufacturer:  Siemens
SKU: LGB3B030B
UPC: 887621220242
Amperage : 30 Amp
Applications : INDUSTRIAL
Connection Type : Low Tab Panelboard Mount
Frame : 125A
Frequency : 50/60 Hz
Interrupt Rating : 65 kAIC
Material : MOLDED CASE CIRCUIT BREAKER
Number of Poles : 3 Pole
Operating Temperature : 40DEGC
Standard : CSA-C22.2,UL 489
Tc Connection : LOW TAB PANELBOARD MOUNT
Trip Type : THERMAL MAGNETIC TRIP UNIT
Type : LGB
Voltage : 480 Volt
Weight : 2.750 lb
Height : 7.05 Inch
Length : 5-1/2 Inch
Width : 5.700 in
