Siemens 3VA5225-6ED61-0AA0

3VA5225-6ED61-0AA0 Product Description

CIRCUIT BREAKER 3VA5 UL FRAME 250 BREAKING CAPACITY CLASS H 65KA @ 480 V 2-POLE, LINE PROTECTION TM210, FTFM, IN=250A OVERLOAD PROTECTION IR=250A FIXED SHORT CIRCUIT PROTECTION II=10 X IN W/O CONNECTION

Specifications:

Brand: SIEMENS
Tension assignée d'isolement Ui 800 V
Max. rated operational voltage Ue with AC 50/60Hz 690 V
Max. rated operational voltage Ue with DC 500 V
Active power loss / for rated value of the current / at
AC / in hot operating state / per device
38.67 W
Active power loss / for rated value of the current / at
AC / in hot operating state / per pole
19.33 W
Mechanical service life (switching cycles) / typical 15 000
Electrical endurance (switching cycles) / at AC-1 / at 380/415 V 50/60 Hz 8 000
Electrical lifetime (switching cycles) / at 480 V / at 50/60 Hz  8 000
