Panasonic DBF-DEDPV

DBF-DEDPV Product Description

The Dryer Exhaust Duct Power Ventilator, DBF-DEDPV, solves problems caused by long duct runs on clothes dryers. By using the powerful ventilator homeowners in single and multi-family buildings can keep their dryer vents free of lint build-up.

Specifications:

Brand: Panasonic
Part Number: DBF-DEDPV
UPC: 628507102050
Motor Voltage: 120V AC 60Hz
Rated Power: 68 Watts
Max Current: 0.56 Amps
Operating RPM: 2,970
Max Static Pressure: 2.004" w.g.
Duct Diameter: 4 inches

Performance Data (CFM @ Static Pressure):

0" w.g.: 192 CFM
0.125" w.g.: 182 CFM
0.25" w.g.: 176 CFM
0.575" w.g.: 163 CFM
0.75" w.g.: 154 CFM
1" w.g.: 130 CFM
1.25" w.g.: 105 CFM
1.5" w.g.: 77 CFM

Features:

Auto-Energizing: Activates automatically when dryer operates
LED Status Indicator: Shows proper operation and alerts for blockages
Pressure Monitoring: Detects and notifies homeowner of duct blockages
Safety Shutdown: Thermal fuse activates in case of dryer fire
Air Velocity: Maintains 1,200 FPM (feet per minute)
Certifications: UL705, CSA C22.2 #113 Clause 12 (DEDPV certified)
Warranty: 10-year limited warranty
