MaxLite LSS1XT8USE4802

LSS1XT8USE4802 Product Description

The MaxLite T8 LED “Lamp Ready” linear Utility Strip provides distributors, contractors, and buyers with a UL listed fixtures designed specifically for LED T8 lamps. These Linear Utility Strips are constructed of the same durable materials as commercial industrial grade fluorescent versions. These fixtures support competitive light output when used with MaxLite brand T8 LED Single/Double ended lamps. These fixtures are verified for use in task, general lighting, assembly, warehouse, and other general lighting applications

Single ended or Dual mode (Single/Double ended) T8 internal driver lamps (4’)
under 17W must be purchased separately from Maxlite for this product.

Features:

 Designed for LED Single/Double Ended lamps – lamps
supplied separately
• Maximum Photometric Efficiency with directional lamps
• Wire Tie tabs std. with fixture, Cable kit mounting accessory
 available
• Key Hole slots at rear for surface mounting
• Knockouts on each end for motion sensor mounting
• 5-Year Warranty

Construction:

• 24 Gauge Steel, white post painted baked on enamel.
• Damp rated housings
• Supplied with ONLY Non-Shunted sockets and Single ended
wiring configurations. For questions contact MaxLite
• 600V rated UL Listed sockets

Control:

• Optional Occupancy sensor available* (on/off)
• MSO option is only for the 2 lamp strip

Specifications:

Manufacturer Part Number:LSS1XT8USE4802
Wattage:2W
Input Voltage:120/277V
UPC:767627949951
Width:1.97 (in)
Height:1.58 (in)
Depth:48.15 (in)

About MaxLite:

MaxLite has been committed to providing energy-efficient lighting products since 1993. One of the first movers into LED technology in the industry, MaxLite offers a complete portfolio of quality certified LED lamps, indoor and outdoor LED luminaires, and a full line of its patented cMax Lighting Controls.
