Magnitude Lighting M40L12DC-AR

M40L12DC-AR Product Description

Magnitude's M40L12DC-AR is the most compact LED driver on the market with a magnetic transformer core. It is equipped with auto-reset breakers, one on the input and one on the output, which protect both the load and driver. The driver is encased in a coated metal box that includes 2 knock-outs, one on each side, to enable easy installation that complies with electrical code requirements.

Specifications:

Manufacturer: Magnitude Lighting
MPN: M40L12DC-AR
UPC: 810020791952
Lighting Technology: LED
Driver: Constant Voltage
Output Current : 1.65A (1650mA)
Input Current: 0.195A
Output Wattage: 20 Watt
Input Voltage: 120VAC
Output Voltage : 12VDC
Frequency: 50/60Hz
Efficiency: 89.8%
Dimming: Phase Dimming
Operating Temperature: -30°C to 45°C
Dimension: 5.60" L x 2.10" W x 2.10" H
Certifications: ETL Listed
Environment: Dry and Damp Location

About Magnitude Lighting:

Magnitude Lighting’s advanced LED drivers and transformers bring innovation to commercial and residential lighting. Magnitude Lighting is an independent LED power company that focuses on LED drivers and transformers for Commercial, Industrial and Residential applications. With a remarkable longevity in LED Technology since 2008, Magnitude Lighting was one of the first companies in the industry to bring dimmable LED drivers into the lighting market.
