Keystone KT-WPLED20-S1-8CSB-VDIM /EM4

KT-WPLED20-S1-8CSB-VDIM /EM4 Product Description

Keystone's 20 watt slim LED wall packs are a great option to provide your building exterior with energy efficient, long lasting LED illumination. Being CCT-selectable, these wall packs allow for a selection between 3000K warm, 4000K neutral and 5000K daylight white light options to suit the users preference and reduce stocking needs for contractors. Their low-profile design and impact-resistant, diffused polycarbonate lens protects the fixture while offering reduced glare for low mounting height applications. A built-in dusk-to-dawn photocell provides even more energy savings by ensuring the light is only on when needed.

The KT-WPLED20-S1-8CSB-VDIM /EM4 is a 20 watt slim LED wall pack in a bronze finish that provides 2,430 lumens of CCT-selectable (3K / 4K / 5K) white light options and the following features:

Features:

120-277V operation
0-10V dimmable
CCT-selectable: select between 3000K warm, 4000K neutral and 5000K daylight white light color temperature options
Emergency battery backup
Integrated photocell
Includes two dip switches protected by a translucent plug to disable the photocell and adjust color temperature as needed
Low-profile design less than 4" deep
Heavy duty die-cast aluminum housing
Impact resistant polycarbonate lens
IP65 rated for wet locations
ADA compliant
DLC Premium
100,000 hour rated

Specifications:

Brand:    Keystone
Manufacturer Part Number:    KT-WPLED20-S1-8CSB-VDIM /EM4
UPC:    843654157498
Lumens:    2,430 Lumens
Wattage:    20 Watts
Input Voltage:    120-277V
Dimmable:    0-10V
Color Temperature:    3000K, 4000K, 5000K
Color:    Bronze
Rated Hours:    50,000 Hours
Min Operating Temp:    -40 Degrees F
CRI:    80+
Special Features:    ADA Compliant, Battery Backup, CCT Selectable, Photocell Installed
Width:    5.81"
Height:    8.61"
