EMCOD ML60S24DC Class 2 60W LED Magnetic Driver Phase Dimmable 120V/12VDC, Black Powder Coated Steel Enclosure
2
sold in last
8
hours
ML60S24DC
$72.00
$69.00
customers are viewing this product
PRODUCT DESCRIPTION
EMCOD ML60S24DC
ML60S24DC Product Description
EMCOD Class 2 60W LED Magnetic Driver Phase Dimmable 120V/12VDC, Black Powder Coated Steel EnclosureSpecifications:
Transformer
Temperature class B(130°C)
Input leads are 18AWG 600V
Output leads are 18AWG 300V
Leads max. operational temperature is 105°C
Thermal manually reset primary breaker 1A
Thermal manually reset secondary breaker 4A
Housing
The actual transformer 60W is encapsulated in the enclosure
The enclosure is Black Powder Coated Steel, NEMA 3R rated
Wiring compartment has 6 knockouts sizes for 3/8 inch screw cable
connectors
Enclosure Temperature does not exceed 75°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 8.13, W = 3.93, D = 1.59
Weight (LBs): 0.39
About EMCOD:
EMCOD is a world-class developer and manufacturer of LED drivers, Lighting and custom made general-purpose transformers for electronic and electrical equipment. Emcod Lighting group’s advanced LED drivers and transformers bring innovation to commercial and residential lighting.Have Questions?Ask a BuyRite Electric Expert
