EMCOD EGP100P
EGP100P Product Description
EMCOD 100W Magnetic Dimmable Double Circuit Transformer, Black Powder Coated Steel Enclosure
Specifications:
Transformer
Temperature class B(130°C)
Two section bobbin completely separated primary and secondary
windings
Input leads are 18AWG 600V
Output leads are 12AWG 300V
Leads max. operational temperature is 105°C
Thermal manually reset primary breaker 2A
per circuit
Housing
The actual transformer 100W is encapsulated in the enclosure
The enclosure is Black Powder Coated Steel, NEMA 3R rated
Wiring compartment has 6 knockouts sizes for 3/8 inch screw cable
connectors
Enclosure Temperature does not exceed 75°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 7.5, W = 3.1, D = 2.94
Weight (LBs): 6
About EMCOD:
EMCOD is a world-class developer and manufacturer of LED drivers, Lighting and custom made general-purpose transformers for electronic and electrical equipment. Emcod Lighting group’s advanced LED drivers and transformers bring innovation to commercial and residential lighting.Have Questions?Ask a BuyRite Electric Expert
