ELCO Lighting EL2699ICEA 3" Electronic Low Voltage Airtight IC Housing for MR16 Bi-Pin
2
sold in last
8
hours
EL2699ICEA
$59.49
customers are viewing this product
PRODUCT DESCRIPTION
Elco Lighting EL2699ICEA
EL2699ICEA Product Description
Line voltage down lighting is a popular choice for lighting residential and commercial spaces because of its comforting light output and easy maintenance. Elco Lighting has a vast selection of line voltage housings and trims in a variety of aperture sizes.FEATURES :
Double wall IC construction, for use in insulated ceilings.Trims sold separately.
Lamp: 50W MAX, 12V, MR16 GU/GX5.3 BiPin LED/Halogen (not included)
Note: Use only dimmers specifically designed for use with magnetic transformers.
SPECIFICATIONS :
Lamp Type : GU5.3 BiPinDamp Location : Listed
Construction:
IC rated for direct contact with insulation, for use in IC or non-IC conditions. Housing adjusts in frame to accommodate up to 1 1/4" ceiling thickness. Airtight housing with gasket to restrict airflow in accordance with ASTM E-283 air-tight requirements. Aluminum housing for greater heat dissipation. Stamped galvanized steel frame.
Installation: Designed for ceiling plenums where 2x6 joists or taller are used. High strength hanger bars can easily be nailed to joists. Maximum hole cutout is 3 3/4". Suitable for T-grid and drop ceiling applications. See installation sheet for detailed information. Access above the ceiling is not required for servicing & repairs occuring after installation (junction box is accessible from below the ceiling).
Junction Box: Positioned to accommodate straight conduit runs. Seven 1/2" trade size pryout conduit knockouts, 4 Romex pryouts with strain relief.
Hanger Bars: Pre-installed hanger bars with True Nail facilitate easy installation in regular lumber, engineered lumber, and laminated beams. Integral T-bar slots for easy installation in T grids. Spans up to 24" and can be repositioned 90°. Score lines allow for tool-free hanger bar size reduction. Integral leveling flange allows for single-person installation while aligning the housing with the joists.
Electrical:
Input Voltage: 120V AC.
Output Voltage: 12V AC.
Magnetic or electronic transformer available.
Thermally protected against improper lamping.
Trims: Compatible with ELCO Low Voltage MR16 trims.
Dimmability:
Magnetic transformer dims with MLV type dimmers.
Electronic transformer dims with ELV type dimmers.
See dimming compatibility list for a list of compatible dimmers.
Note: Lamp used may affect dimmability.
Lamp: Designed for use with GU5.3 MR16 lamps up to 50W.
Warranty: ELCO Lighting warrants products will be free from defects in materials and workmanship for a period of 3 years.
Labels and Listings:
UL Listed for Damp Location.
UL Listed for Wet Location with Shower trims.
UL Listed for Feed Through.
UL Listed for Direct Contact with Insulation and Combustible Material. Airtight per ASTM E-283.
Install a JA8-2016-E lamp/luminaire for Title 24 Compliance.
